MC-J10B 2MP Super Starlight IPC Module – SSC335 + Sony IMX307 Dual-Light
 | MC-J10B 2MP Super Starlight IPC Module – Sony IMX307 Dual-LightSolution: SSC335 + Sony IMX307 2MP 1/2.8″ CMOS Encoding: H.265+ / H.265 / H.264 Main Stream: 3MP@25fps / 1080P@30fps Min. Illumination: Color 0.01 Lux (super starlight) Dual Light: Active IR + Active warm light Storage: TF card up to 128 GB Network: RJ45 10/100M, ONVIF/HTTP/RTSP/P2P Size: 38×38×15 mm | Power: DC12V / POE, 1.2W |
Features
*1/2.8″ Sony IMX307 2MP ultra-low illumination ceramic CMOS – color at 0.01 Lux
*H.265+/H.265/H.264 encoding; CBR/VBR; bitrate/frame rate adjustable
*Active IR + active warm light dual-light function
*TF card local storage, up to 128 GB – standalone NVR-free deployment
*Motion detection, OSD customization, JPEG capture
*P2P cloud service; IP filtering; sound alarm linkage (customizable)
*License plate recognition; auto zoom support
*PTZ linkage support
*3D noise reduction; wide dynamic range; anti-overexposure; defogging
*Integrated IRCUT circuit – auto/external/manual/timer control
*G711U/G711A audio; two-way voice intercom; audio-video synchronization
*ONVIF; HTTP/RTSP/DHCP/NTP/P2P; optional GB28181, RTMP
*Mobile APP: VideoLink (iOS & Android); SDK: Windows, Android, Linux
*IO interface: electric zoom and auto-focus lens support
*Lightning protection: GB/T17626.5 & IEC61000-4-5
*38×38×15mm compact PCB; DC12V or POE 1.2W max; OEM/ODM available
Specifications
| General | Description |
| Model | MC-J10B |
| Main Control Chip | MSTAR SSC335 |
| Image Sensor | Sony IMX307, 2MP, 1/2.8″ ultra-low illumination ceramic CMOS |
| Min. Illumination | Color: 0.01 Lux |
| Signal-to-Noise Ratio | 50 dB |
| Video | Description |
| Video Encoding | H.265+ / H.265 / H.264 |
| Main Stream | 3MP @ 25fps; 1080P/720P/D1 @ 30fps |
| Sub Stream | D1/VGA/640×360/CIF @ 30fps |
| CBR/VBR | Supported |
| Storage | Description |
| TF Card | Supports up to 128 GB |
| Lighting | Description |
| Light Mode | Active IR (infrared) + Active warm light (dual light) |
| IRCUT | Integrated circuit; auto / external / manual / timer control |
| Audio | Description |
| Audio Codec | G711U / G711A |
| Two-way Audio | Supported |
| Smart Features | Description |
| Functions | Motion detection, OSD, JPEG capture, P2P cloud, IP filtering |
| Alarm | Sound alarm linkage (customizable), PTZ linkage |
| IO Interface | Electric zoom and auto-focus lens support |
| Network | Description |
| Network Interface | 1 × RJ45, 10/100M, 2KV lightning protection |
| Protocols | HTTP, RTSP, DHCP, NTP, ONVIF, P2P; optional GB28181, RTMP |
| Mobile APP | VideoLink (iOS & Android) |
| SDK | Windows, Android, Linux |
| Power & Environment | Description |
| Power Supply | DC 12V or POE, 1.2W max |
| Working Temperature | -30°C to +85°C |
| Dimensions | 38 mm × 38 mm × 15 mm |
SSC335 OpenIPC Compatibility
MC-J10B is a Videolink / MC IPC camera module based on SigmaStar SSC335 with IMX307.
Can MC-J10B run OpenIPC?
OpenIPC has an upstream SSC335 firmware build. The inspected infinity6b0 loader contains an IMX307 sensor entry. This is a useful software starting point for MC-J10B, but it does not verify the fitted PCB, flash layout or image-tuning profile.
OpenIPC is also searched as “Open IPC”. Compatibility refers to alternative firmware; it does not mean that the factory app, AI detection or original video modes will carry over. Confirm the full SoC and sensor IDs, flash type, PCB revision and intended firmware before conversion.
Evidence reviewed: 16 September 2026. OpenIPC technical reference.
